Galletti ACQVARIA AQ10Q0B0 Technical Manual

Cassette fan coils with on/off motor
Hide thumbs
Table of Contents

Advertisement

Quick Links

ACQVARIA
cassette fan coils with On/OFF motor
PLUS
» Reliability and sturdiness in a compact design
» Fresh air with direct or mixed introduction
» Heat exchanger up to 3 rows
» Condensate drainage pump for height differences of up
to 0.9 m
» Air intake and diffusion grille in two colors (RAL9010
and RAL9030)
» Reduced installation and commissioning time
Technical manual
3 - 10 k W
2
4
Supervision GARDA
2 pipes systems
4 pipes systems
Touch screen device Recess ceiling-mount
EN

Advertisement

Table of Contents
loading

Related Manuals for Galletti ACQVARIA AQ10Q0B0

Summary of Contents for Galletti ACQVARIA AQ10Q0B0

  • Page 1 Technical manual ACQVARIA cassette fan coils with On/OFF motor 3 - 10 k W Supervision GARDA 2 pipes systems 4 pipes systems Touch screen device Recess ceiling-mount PLUS » Reliability and sturdiness in a compact design » Fresh air with direct or mixed introduction »...
  • Page 2 Dear Customer, Thank you for placing your trust in one of the products of Galletti S.p.a This product is the result of our work and our commitment to design, research, and production and has been made from the finest materials, employing state-of-the-art components and production technology.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS 122 CLEANING THE AIR INTAKE GRILLE            p 48 MAIN FEATURES                             p 4 123 CLEANING THE CABINET                      p 48 OPERATING LIMITS                             p 4 124 ELECTRIC CONTROL BOARD                  p 49...

  • Page 4: Main Features

    The design and colour, RAL9003 or RAL9010, of the air intake ing interior comfort. and diffusion louvre guarantee optimal integration into the sus- ACQVARIA leverages the entire Galletti, MYCOMFORT, EVO , and pended ceiling panels. Easy access to the air filter for cleaning TED microprocessor controller platform that incorporate sophis- operations.

  • Page 5: 14 Grille Configurator                        P

    GRILLE CONFIGURATOR Family Version Size Control Variants Release GR grid 30 AQ10-20 F wire 1 RAL9003 A rst release 60 AQ40-50-60 2 RAL9010 AVAILABLE ACCESSORIES Electronic microprocessor control panels with display DIST MY COMFORT controller spacer for wall mounting EVO-2-TOUCH 2.8”...

  • Page 6: Main Components

    MAIN COMPONENTS STRUCTURE Made of galvanised steel sheet with internal polyurethane foam available for connection to ducts. There are systems on the unit coating and external closed-cell polyethylene foam to guaran- for anchoring it to the ceiling. The electrical wiring is housed in tee heat and sound insulation.

  • Page 7: 28 Exploded View                               P

    EXPLODED VIEW » 22 Exploded view, units AQ 10-20 1. Locking clips 2. Tie rods 3. Condensate drip tray 4. Condensate drainage pump 5. Heat exchanger 6. Fan drive assembly 7. External insulation 8. Internal insulation 9. Lateral sheet metal 10.
  • Page 8 » 23 Exploded view, units AQ 40-50-60 1. Locking clips 2. Tie rods 3. Condensate drip tray 4. Condensate drainage pump 5. Heat exchanger 6. Fan drive assembly 7. External insulation 8. Internal insulation 9. Lateral sheet metal 10. Sheet metal back 11.

  • Page 9: Air Range

    AIR RANGE • Flap inclination 45° » Air range 2T Model AQ10 AQ20 AQ40 AQ50 AQ60 Air range X (m) Height Y (m) Distance Z (m) » Air range 4T Model AQ10 AQ20 AQ40 AQ60 Air range X (m) Height Y (m) Distance Z (m)

  • Page 10: Installation

    INSTALLATION WARNING: unit installation and start-up must be entrusted to those of the main power supply. to competent personnel and performed in a workmanlike WARNING: Install the unit, circuit breaker (IL) and/or any re- manner, in accordance with current regulations. mote controls in a place out of reach of persons who may be WARNING: It is mandatory to install the 3-way (or 2-way)
  • Page 11 Galletti controls implement a logic that makes it possible to set Ū Bleed air from the exchanger by means of the air vent valves a fixed speed between minumum, medium and maximum, or located next to the water connections of the coil.
  • Page 12 » Fig1 » Fig3 » Fig2 DIMENSIONAL UNIT ASSEMBLY Ū use the dimensional drawings to determine the position of D - Distance from unit to false Model the suspension rods (Fig.4 AQ 10-20) (Fig.5 AQ 40-50-60) ceiling Ū Position the suspension rods (not supplied) in place. ACQVARIA 10-20 Ū...
  • Page 13 » Fig5 AQ 40-50-60 » Fig8 » Fig6 » Fig9 AQ10-20 » Fig7 » Fig10 AQ40-50-60 1. nut + washer 2. Washer + nut + lock nut WC66000496 All copying, even partial, of this manual is strictly forbidden...
  • Page 14 4.2.1 Front panel/grille assembly » Fig12 The front panel/grille, available in RAL9003 and RAL9010 ver- sions, is delivered in a separate cardboard box: Ū AQYGR30 for models AQ 10-20 Ū AQYGR60 for models AQ 40-50-60 Before installing the front panel: (Fig.11 ) Ū...

  • Page 15: Rated Technical Data

    RATED TECHNICAL DATA » Rated technical data ACQVARIA - 2 pipes ACQVARIA AQ10Q0B0 AQ20Q0B0 AQ40Q0B0 Speed Total cooling capacity 1,70 1,97 2,53 2,39 3,55 4,31 4,64 5,36 7,01 Sensible cooling capacity 1,33 1,60 2,14 1,66 2,53 3,18 3,42 3,99 5,29 FCEER class Water flow 1223...

  • Page 16: Weights

    » Rated technical data ACQVARIA - 4 pipes ACQVARIA AQ10Q0BB AQ20Q0BB AQ40Q0BB AQ60Q0BB Speed Total cooling capacity DF 1,56 1,85 2,35 2,01 2,83 3,38 4,74 6,60 7,45 5,83 8,48 9,00 Sensible cooling capacity DF 1,24 1,49 1,94 1,49 2,22 2,77 3,47 5,04 5,81...

  • Page 17: Performances

    PERFORMANCES Galletti has developed on its www.galletti.com web-area the new On-LInE integrated platform for product selection, configuration and the making of the economic offer. The software, whose use is easy and intuitive, allows the identification of the desired products by calculating their performances based on real working conditions and their configuration helping the user in choosing options and accessories.

  • Page 18: Sound Levels

    SOUND LEVELS » 2 pipes ACQVARIA AC Speed 125 Hz 250 Hz 500 Hz 1000 Hz 2000 Hz 4000 Hz 8000 Hz 37,6 35,6 32,1 26,8 17,8 10,2 10,8 AQ10Q0B0 41,1 38,8 35,2 32,3 24,7 11,7 48,2 45,9 43,5 39,3 36,0 26,2 13,5...

  • Page 19: Electrical Connection Diagrams

    ELECTRICAL CONNECTION DIAGRAMS WARNING: The traced electrical connections must be made by the installer. For each unit an (IL) switch should be mounted on the power supply, with opening contacts at a distance of at least 3 mm and a suitable protection fuse (F) .
  • Page 20 » 92 Wiring diagram My Comfort base AQ 40-50-60 FLOAT :Fanmotor Condensate drainage pump FLOAT: Float switch VC/H: Water valve (hot and cold) 2A fuse (not supplied) Circuit breaker (not supplied) Fast-on connector Umidity sensor Water temperature sensor Room temperature sensor BK(M): Black=maximum speed BU(M): Blue=Medium speed motor RD(M): Red=minimum speed motor...
  • Page 21 » 93 My Comfort medium wiring diagram for AQ 10-20 FLOAT :Fanmotor Condensate drainage pump FLOAT: Float switch VC/H: Water valve (hot and cold) 2A fuse (not supplied) Circuit breaker (not supplied) Fast-on connector Umidity sensor Water temperature sensor Room temperature sensor BK(M): Black=maximum speed GY(M): Grey=medium speed motor WH(M): White=minimum speed motor...
  • Page 22 » 94 My Comfort Medium wiring diagram for AQ 40-50-60 FLOAT :Fanmotor Condensate drainage pump FLOAT: Float switch VC/H: Water valve (hot and cold) 2A fuse (not supplied) Circuit breaker (not supplied) Fast-on connector Umidity sensor Water temperature sensor Room temperature sensor BK(M): Black=maximum speed BU(M): Blue=Medium speed motor RD(M): Red=minimum speed motor...
  • Page 23 » 95 My Comfort Large wiring diagram for models AQ 10-20 :Fanmotor Condensate drainage pump FLOAT: Float switch VC/H: Water valve (hot and cold) 2A fuse (not supplied) Circuit breaker (not supplied) Fast-on connector Umidity sensor Water temperature sensor Room temperature sensor BK(M): Black=maximum speed GY(M): Grey=medium speed motor WH(M): White=minimum speed motor...
  • Page 24 » 96 My Comfort Large wiring diagram for models AQ 40-50-60 :Fanmotor Condensate drainage pump FLOAT: Float switch VC/H: Water valve (hot and cold) 2A fuse (not supplied) Circuit breaker (not supplied) Fast-on connector Umidity sensor Water temperature sensor Room temperature sensor BK(M): Black=maximum speed BU(M): Blue=Medium speed motor RD(M): Red=minimum speed motor...
  • Page 25 » 97 TED2T wiring diagram for models AQ 10-20 FLOAT For controls TED electrical connections, follow the paragraph wirings diagrams: Fan motor Condensate drainage pump FLOAT: Float switch VC/H: Water valve (hot and cold) 2A fuse (not supplied) Circuit breaker (not supplied) Fast-on connector Water temperature sensor Room temperature sensor...
  • Page 26 » 98 TED2T wiring diagram for models AQ 40-50-60 FLOAT For controls TED electrical connections, follow the paragraph wirings diagrams: Fan motor Condensate drainage pump FLOAT: Float switch VC/H: Water valve (hot and cold) 2A fuse (not supplied) Circuit breaker (not supplied) Fast-on connector Water temperature sensor Room temperature sensor...
  • Page 27 » 99 TED4T wiring diagram for models AQV 10-20 FLOAT For controls TED electrical connections, follow the paragraph wirings diagrams: Fan motor Condensate drainage pump FLOAT: Float switch VC/H: Water valve (hot and cold) 2A fuse (not supplied) Circuit breaker (not supplied) Fast-on connector Water temperature sensor Room temperature sensor...
  • Page 28 » 910 TED4T wiring diagram for models AQV 40-50-60 FLOAT For controls TED electrical connections, follow the paragraph wirings diagrams: Fan motor Condensate drainage pump FLOAT: Float switch VC/H: Water valve (hot and cold) 2A fuse (not supplied) Circuit breaker (not supplied) Fast-on connector Water temperature sensor Room temperature sensor...
  • Page 29 » 911 EVO BOARD wiring diagram for models AQ 10-20 Fan motor Condensate drainage pump FLOAT: Float switch 2A fuse (not supplied) Circuit breaker (not supplied) Fast-on connector Umidity sensor Water temperature sensor Room temperature sensor BK(M): Black=maximum speed GY(M): Grey=medium speed motor WH(M): White=minimum speed motor BU(M): Blue= common BN (FLOAT):...
  • Page 30 » 912 EVO BOARD wiring diagram for models AQ 40-50-60 Fan motor Condensate drainage pump FLOAT: Float switch 2A fuse (not supplied) Circuit breaker (not supplied) Fast-on connector Umidity sensor Water temperature sensor Room temperature sensor BK(M): Black=maximum speed BU(M): Blue=Medium speed motor RD(M): Red=minimum speed motor BU(M): Blue= common BN (FLOAT):...

  • Page 31: Overall Dimensions

    10 OVERALL DIMENSIONS » 101 Dimensional drawing AQ 10-20, 2 pipes LEGEND Electric box Condensate discharge ø 10 Water outlet ø 1/2" female gas Water inlet ø 1/2" female gas WC66000496 All copying, even partial, of this manual is strictly forbidden...
  • Page 32 » 102 Dimensional drawing AQ 40-50-60, 2 pipes 92,5 LEGEND Electric box Condensate discharge ø 10 Water outlet ø 3/4" female gas Water inlet ø 3/4" female gas ACQVARIA TECHnICAL MAnuAL...
  • Page 33 » 103 Dimensional drawing AQ 10-20, 4 pipes LEGEND Electric box Condensate discharge ø 10 Cooling exchanger water outlet, 1/2” gas F Cooling exchanger water inlet, 1/2” gas F Heating exchanger water outlet, 1/2” gas F Heating exchanger water inlet, 1/2” gas WC66000496 All copying, even partial, of this manual is strictly forbidden...
  • Page 34 » 104 Dimensional drawing AQ 40-60, 4 pipes 92,5 LEGEND Electric box Condensate discharge ø 10 Cooling exchanger water outlet, 3/4” gas F Cooling exchanger water inlet, 3/4” gas F Heating exchanger water inlet, 1/2” gas F Heating exchanger water outlet, 1/2” gas F ACQVARIA TECHnICAL MAnuAL...

  • Page 35: Accessories

    11 ACCESSORIES E2TY - 2.8" touch screen user interface Touch screen 2.8" user panel for EVO-2-TOUCH control EVO, frame in natural brushed aluminium. (to combined with EVO BOARD) Main functions: • 2.8'' capacitive touch screen display • Integrated temperature and humidity probe •...
  • Page 36 • Water consent on the basis of temperature LED503 - Recess wall-mounted microprocessor control The proposed microprocessor control panels for Galletti indoor units is completed by the LED503 command with LED display that is designed for recess wall mounting. CONTROLLER The control software developed by the Galletti Software Dept., features:...
  • Page 37 MOB - Cabinet for installation of the cassette in spaces without a suspended ceiling RAL 9010 Color BAR - Spigot for introduction of mixed renewal air • The BAR accessory is a fitting for Ø100 pipe to be connected to the inlets located on the unit. •...
  • Page 38 11.1 2- OR 3-WAY MOTOR-DRIVEN VALVE KITS WARNING: The installation of a valve kit on the fan coil unit NOTE: for units AQ10-AQ20 it is necessary to install the is mandatory ACQVARIA. 3-way valves inclined so as to comply with the space con- straint regarding the height of the base unit.
  • Page 39 » 3-way valve kit - 2 pipes, AQ 10-20 NOTE: The actuator is not shown. Water outlet Water inlet » 2-way valve kit - 4 pipes, AQ 10-20 Cold water outlet Hot water inlet Cold water inlet NOTE: The actuators are not shown. Hot water outlet WC66000496 All copying, even partial, of this manual is strictly forbidden...
  • Page 40 » 3-way valve kit - 4 pipes, AQ 10-20 Cold water outlet Hot water inlet NOTE: The actuators are not shown. Cold water inlet Hot water outlet » 2-way valve kit - 2 pipes, AQ 40-50-60 NOTE: The actuator is not shown. Water outlet Water inlet ACQVARIA...
  • Page 41 » 3-way valve kit - 2 pipes, AQ 40-50-60 NOTE: The actuator is not shown. Water outlet Water inlet » 2-way valve kit - 4 pipes, AQ 40-50-60 Cold water outlet Hot water inlet Cold water inlet NOTE: The actuators are not shown. Hot water outlet WC66000496 All copying, even partial, of this manual is strictly forbidden...
  • Page 42 » 3-way valve kit - 4 pipes, AQ 40-50-60 Cold water outlet Hot water inlet NOTE: The actuators are not shown. Cold water inlet Hot water outlet 11.2 PRESSURE-INDEPENDENT MOTOR-DRIVEN 2-WAY VALVE KIT WARNING: The installation of a valve kit on the fan coil unit Ū...
  • Page 43 » 2-way valve kit VPIC - 2 pipes, AQ 10-20 Water outlet Water inlet » 2-way valve kit VPIC - 4 pipes, AQ 10-20 Cold water outlet Hot water outlet Cold water inlet Hot water inlet WC66000496 All copying, even partial, of this manual is strictly forbidden...
  • Page 44 » 2-way VPIC valve kit - 2 pipes, AQ 40-50-60 Water outlet Water inlet » 2-way VPIC valve kit - 4 pipes, AQ 40-50-60 Cold water outlet Hot water outlet Cold water inlet Hot water inlet ACQVARIA TECHnICAL MAnuAL...

  • Page 45: 114 Connection For Intake Of Fresh Air To

    11.3 AUXILIARY WATER DRIP TRAY FOR COLLECTING CONDENSATE FROM THE CONTROL VALVES The auxiliary water drip tray is supplied with the base unit to- » Fig16 gether with two fastening screws. Its function is to collect the condensate generated by the control valves and to convey it inside the main condensate drip tray of the unit.
  • Page 46 11.5 CONNECTION FOR OUTLET OF AIR IN ADJACENT ROOMS The units are equipped with 2 rectangular air outlets for connec- Ū The PMAA accessory is available: a plenum to connect the tion to separate distribution ducts. rectangular outlets located on the unit to the round distri- Ū...
  • Page 47 11.6 CONNECTION FOR INTRODUCTION OF FRESH AIR INTO ROOM The units are equipped with 2 rectangular arrangements for Ū The PAR accessory is available, consisting of a duct and a connection to ducts for the introduction of fresh air directly into plenum: fresh air is introduced into the installation room by- the room.

  • Page 48: Maintenance

    12 MAINTENANCE For safety reasons, before carrying out any maintenance or cleaning the air filter, the internal and external exchangers, the cleaning jobs, turn off the unit by moving the fan speed se- cabinet, and cleaning and protecting the condensate drip trays. lector to "OFF"...
  • Page 49 12.4 ELECTRIC CONTROL BOARD Once a year, check that the electrical wires are properly tightened on their terminal blocks. 12.5 ADDITIONAL MAINTENANCE Inspecting, cleaning, or replacing internal components requires » Fig23 the removal of the main condensate tank. Tank removal (Fig. 23): Ū...
  • Page 50 Romagnoli 12/a 40010 Bentivoglio (BO) - Italy Ph. +39 051/8908111 - Fax +039 051/8908122 unI En ISO 9001 and unI En ISO 45001 www.galletti.com...
