5.13 TOTALIZER MODULES
There are eight Totalizer Modules that can be configured separately. Each module provides a totalization (integration) of a specified in-
put. Sampling occurs once a second whenever the input parameter contains a valid datapoint specification.

Table 5-13. Totalizer Modules

Parameter
It is an assignable 10 character name that is
Tag
associated with each totalizer.
Engineer- Each totalizer has an assignable 10 character name
ing Units that appears on the display as the units of measure.
This parameter designates the datapoint to be
Input totalized. it can be any B, C, or H datapoint, e.g.,
C100 for totalizing CON0 PV.
The value of the input is multiplied by this parameter
prior to being summed to the running total. This
parameter is used for both scaling and time interval
integration. For example, if AI0 is in M gallons/day, in
order to totalize in k gallons the scale factor (SF)
would be:
Scale Fac-
SF = [Units Conversion] X [Time Base Conversion]
tor
SF = [1000 k gal / M gal] X [(1 day/24 hrs) X (1 hr/60
mins) X (1 min/60 sec) X (1 sec/sample)] =
1000/86400 = 0.01157
Note: The time between totalizer updates is one
second.
This parameter specifies the maximum value of the
Rollover totalizer. When the total reaches this value it is reset
Value to 0.0; however, totalizing continues. This value must
be a positive number.
Dropout When the input value is less than this value, no
Value change in the total occurs.
This parameter acts like a momentary switch. When
Reset this parameter is set to 1 the total is forced to 0.0 and
then this parameter is reset to 0 .
Definition Symbol 0 1 2 3
TAG A092 A094 A096 A098 A100 A102 A104 A106
EU A093 A095 A097 A099 A101 A103 A105 A107
TMPT
F216 F217 F218 F219 F220 F221 F222 F223
(0-7)
TMF
C318 C320 C322 C324 C326 C328 C330 C332
(0-7)
TMM
H048 H049 H050 H051 H052 H053 H054 H055
(0-7)
TMD
C319 C321 C323 C325 C327 C329 C331 C333
(0-7)
TMR
L232 L233 L234 L235 L236 L237 L238 L239
(0-7)
1 of 2
4 5 6 7 Default
0
0
0
0
