5.10 STATUS MODULES (SDT0 AND SDT1)
There are two Status Modules (SDM) that can be configured separately. The two Status Modules each provide indication and push but-
ton access control for eight logical points in the controller. How the indicators appear for given conditions and alarms is dependent upon
the configuration selections entered in the Status Modules. The display handler index numbers for the discrete status displays are 21
and 22, which correspond to status modules SDT0 and SDT1 respectively.
Table 5-10. Status Modules (SDT0 and SDT1)
Title
Tag
Point 1 Name
Point 2 Name
Point 3 Name
Point 4 Name
Point 5 Name
Point 6 Name
Point 7 Name
Point 8 Name
Point 0 State
Point 1 State
Point 2 State
Point 3 State
Point 4 State
Point 5 State
Point 6 State
Point 7 State
Definition
This parameter is a 10 character assignable name.
This is a 10 character name (e.g., PUMP ALARM) of the
status point or two 5 character words (e.g., ON OFF, IN
OUT, START STOP). Each status point of an SDM has
an associated name.
This parameter indicates the current condition of the
individual points, which can be either 0 or 1 . It can be
set to a 0 or 1 with the push buttons at the discrete
status display or by F-TRAN, FCIM,or FCS execution.
Atom SDT0 SDT1
TAG A054 A063 SDT0 , SDT1
STA A055 A064 SDT0 = A, SDT1 = I
STB A056 A065 SDT0 = B, SDT1 = J
STC A057 A066 SDT0 = C, SDT1 = K
STD A058 A067 SDT0 = D, SDT1 = L
STE A059 A068 SDT0 = E, SDT1 = M
STF A060 A069 SDT0 = F, SDT1 = N
STG A061 A070 SDT0 = G, SDT1 = O
STH A062 A071 SDT0 = H, SDT1 = P
SSA L336 L344
SSB L337 L345
SSC L338 L346
SSD L339 L347
SSE L340 L348
SSF L341 L349
SSG L342 L350
SSH L343 L351
1 of 4
Default
0
0
0
0
0
0
0
0
