5.11 PARAMETER MODULES
These modules provide quick operator access to any three selected datapoints (e.g., Alarm Limits 1 & 2 and Alarm Dead Band) without
the necessity of entering Engineer mode and addressing the datapoints. There are eight Parameter Modules (0-7) that can be configured
separately.
Table 5-11. Parameter Modules
Title
Title It is an assignable 10 character name that appears
with the parameter display.
Point 1 It is an assignable 10 character name for the Point
Name 1 Designator.
Point 2 It is an assignable 10 character name for the Point
Name 2 Designator.
Point 3 It is an assignable 10 character name for the Point
Name 3 Designator.
Point 1 A database datapoint whose contents will be
Desig- displayed under the Point 1 Name (e.g., C103 to
nator display the Alarm Limit 1 setting).
Point 2 A database datapoint whose contents will be
Desig- displayed under the Point 2 Name (e.g., C104 to
nator display the Alarm Limit 2 setting).
Point 3 A database datapoint whose contents will be
Desig- displayed under the Point 3 Name (e.g., C105 to
nator display the Alarm Dead Band).
Modify When this value is 1 , the datapoints in this module
Disable can not be altered with the push buttons. The
values of these datapoints are only for display
purposes. When this value is 0 , the datapoints in
this module can be altered by the operator with the
push buttons when this module is displayed.
Display This is the index number for the display that
provides access through the parameter module.
Definition Atom 0 1 2
TAG A010 A014 A018 A022 A026 A030 A034 A038
PNA A011 A015 A019 A023 A027 A031 A035 A039
(0-7)
PNB A012 A016 A020 A024 A028 A032 A036 A040
(0-7)
PNC A013 A017 A021 A025 A029 A033 A037 A041
(0-7)
PDA F084 F087 F090 F093 F096 F099 F102 F105
(0-7)
PDB F085 F088 F091 F094 F097 F100 F103 F106
(0-7)
PDC F086 F089 F092 F095 F098 F101 F104 F107
(0-7)
PMD L312 L313 L314 L315 L316 L317 L318 L319
(0-7)
13 14 15
3 4 5 6 7
16 17 18 19 20
Default
0
