• The existing contents of DATAPOINT C115 are dis-
played (shown as 100.000 in this example).
• To change the value of C115, first shift the C115 con-
tents all the way right by pressing and holding the
button.
• Replace the "1" with a "2" by pressing the
until a "2" appears on the entry line, as shown in the
screen to the right.
• Enter the two additional zeros by using the
buttons as discussed previously.
• The screen should now look as shown on the right.
• Replace the current C115 value with the new one by
pressing the F3 button.
• If you don't want to make the change, the edit may be
aborted by pressing the F1 button.
• After pressing F3, the display changes back to the
DATAPOINT display as shown to the right.
• Notice the change in bar-graph scale to 200.0.
• Press the Mode button
operator mode.
Section 3. Product Description
to return the instrument to
button
and
3-15
