5.4 ANALOG INPUT MODULES (AI0-8)
The Analog Input Modules (AI0-8) are used to configure the characteristics of each input. Inputs AI4 through AI8 are active only if the ap-
propriate hardware option is installed. The nine Analog Input Modules are listed in Table 5-4. Each module can be configured sepa-
rately.
Table 5-4. Analog Input Modules (AI0-8)
Title Definition
Analog Input This is the value in engineering
units of the measured input after all
signal conditioning has been
applied.
Engineering This value determines the upper
Span range the analog input represents
in engineering units. The upper
range value equals Engineering
Zero plus Engineering Span.
Engineering This is the lower range value.
Zero
Digital Filter This entry controls a first order filter
Index that is applied to the input signal.
The time constant is entered as an
index value as follows:
0 - None (no effect),
1 - 0.05 s 6 - 3.1 s
2 - 0.1 s 7 - 6.3 s
3 - 0.3 s 8 - 12.7 s
4 - 0.7 s 9 - 25.5 s
5 - 1.5 s 10 - 51.1 s
Signal Base This value specifies the signaling
range of the input.
0 - 4-20 mA (1 - 5V)
1 - 0-20 mA (0 - 5V)
Atom AI0
AI H000 H001 H002
(0-8)
SPAN C256 C257 C258
(0-8)
ZERO C276 C277 C278
(0-8)
DFILT B269 B270 B271
(0-8)
11 - 102 s
12 - 205 s
13 - 410 s
14 - 819 s
15 - 1638 s
BASE L416 L417 L418
(0-8)
AI1 AI2 AI3 AI4
H003 H004 H005 H006 H007 H008
C259 C260 C261 C262 C263 C264
C279 C280 C281 C282 C283 C284
B272 B273 B274 B275 B276 B277
L419 L420 L421
1 of 3
AI5 AI6 AI7 AI8 Default
0
100/0
0
3
L422 L423 L424 0
