Table D-13. System Module
Page *
Unit Tag Name
Function Index
Scan Index
Execute
Background Program
Background Scan Index
Link List Load
Forced Output
Power Up
Counter Mode
Seconds
Minutes
Counter
Hours
Month
Day
Year
Instrument Address *
Baud Rate *
Comm.
No Parity *
No Byte Stuffing *
Datalink Disable *
Display Program
Display Brightness Index
Display Number of [Display] Groups
Number of Displays per Group
No Alarm Line Annunciation
Alarm Line Output
Control Module Selector *
PID Control Mode *
Lowest TR Minutes *
EZ-Tune
Max. Allowed PV Deviation *
Output Step Change Value 0 *
Initial PV Response Limit *
Enable Tuning Parameter Limits *
Automatic Tuning Parameter Entry *
Appendix D. Database
Name Atom Datapoint
TAG A008
FIX B000
SCAN B003
BACK B008
BSCAN B006
LLD B016
FXM B333
PWRUP L066
CMODE L075
SEC B257
MIN B258
HOURS B259
DAY B260
MONTH B261
YEAR B262
IA B001
BR B002
CP L256
CB L258
DLD L257
DSPL B005
BRIGHT B012
MDG B017
MDS B018
NALIN L063
ALINE A009
LPS B385
CM B386
TLIM C387
DPV C380
DOUT C381
DPPV C378
PLIM L520
APLD L522
Default
MC5000
0
1
0
1
0
0
0
0
0
0
0
0
0
0
0
253
0
0
0
3
4
1
5
0
ALARM
0
0
0
0
0
2
1
0
