ABB ControlIT 53MC5000 Instruction Manual page 154

5.6 DISCRETE INPUT MODULES (DI0-17)
The Discrete Input Modules (DI0-17) generate logic levels based on the applied voltages or contact condition on the associated termi-
nals. Inputs DI2-17 are active only when the appropriate hardware options are installed. The 18 Discrete Input Modules are provided in
Table 5-6. Each one can be configured separately (total combined DIs and DOs for controller cannot exceed 18).
Table 5-6. Discrete Input Modules (DI0-17)
Title Definition
Discrete Input This is an indication of the
applied signal level after INV
conditioning (see below).
Input Invert This parameter specifies the
signaling protocol to use for the
DI value (see above):
0 - 1-ON
1 - 0-ON
Input: Open, 4-24VDC (OFF)
INV 0, 1-ON DI=0
INV 1, 0-ON DI=1
Input: Closed, <1VDC (ON)
INV 0, 1-ON DI=1
INV 1, 0-ON DI=0
Tag Name It is an assignable 10 character
name for the contact control
input.
Title Definition
Discrete Input
Same as above.
Input Invert
Tag Name
Atom DI DI DI
0 1 2
DI L000 L001 L002
(0-8)
INV L264 L265 L266
(0-8)
TAG A262 A263 A264
Atom DI DI DI
9 10 11
DI L009 L010 L011
(9-17)
INV L273 L274 L275
(9-17)
TAG A271 A272 A273
DI DI DI DI
3 4 5 6
L003 L004 L005 L006 L007
L267 L268 L269 L270 L271
A265 A266 A267 A268 A269
DI DI DI DI
12 13 14 15
L012 L013 L014 L015 L016
L276 L277 L278 L279 L280
A274 A275 A276 A277 A278
DI DI Default
7 8
L008 0
L272 0
A270
DI DI Default
16 17
L017 0
L281 0
A279
