Table 9-3. CS4 Automatic/Manual Station Datapoints

Data-
point Table Module
C256 5-4 AI0
C276 5-4 AI0
B269 5-4 AI0
L416 5-4 AI0
L440 5-4 AI0
C258 5-4 AI2
C278 5-4 AI2
B271 5-4 AI2
L418 5-4 AI2
L442 5-4 AI2
L119 5-9 CON0
C259 5-4 AI3
C279 5-4 AI3
B272 5-4 AI3
Section 9. CS4 - Automatic/Manual Station
AI0 - Auto Input
Engineering Span - Enter a value, that when added to the
Engineering Zero value, will produce an upper range value in
engineering units that represents the Auto Input upper range
signal value.
Engineering Zero - Enter a value that represents in
engineering units the Auto Input lower range signal value.
Digital Filter Index - This is a first order filter that can be
applied to the Auto Input signal. See Table 5-4 for input
values.
0-5 V Input - Enter a value that matches the voltage range of
the Auto Input signal. 1 = 0 - 5 V range; 0 = 1 - 5 V range.
Square Root Signal - It is used if the Auto Input signal is a
squared value. 0 = input is already linear; 1 = square root to
restore linearization.
AI2 - Alarmed Variable
Engineering Span - Enter a value, that when added to
Engineering Zero, will produce an upper range value in
engineering units that represents the Alarmed Variable upper
range signal value.
Engineering Zero - Enter a value that represents in
engineering units the Alarmed Variable lower range signal
value.
Digital Filter Index - This is a first order filter that can be
applied to the Alarmed Variable signal. See Table 5-4 for
input values.
0-5 V Input - Enter a value that matches the voltage range of
the Alarmed Variable signal. 1 = 0 - 5 V input range; 0 = 1 -
5 V input range.
Square Root Signal - It is used if the Alarmed Variable input
is a squared signal value that must be linearized. 0 = input
is already linear; 1 = square root to restore linearization.
AI3 - Tracking Input (Output Tracking)
Output Track Enable - This datapoint must be configured to a
1 so that Output Tracking can be enabled when DI0 is an
open contact.
Engineering Span - Enter a value, that when added to the
Engineering Zero value, will produce an upper range value in
engineering units that represents the tracking input upper
range signal value.
Engineering Zero - Enter a value that represents in
engineering units the tracking input lower range signal value.
Digital Filter Index - This is a first order filter that can be
applied to the tracking input signal. See Table 5-4 for input
values.
Title and Function
1 of 3
De-
fault
100
0
3
0
0
0
0
3
0
0
0
0
0
3
9-5
