5.9 CONTROLLER MODULES (CON0-3)

These modules affect the action of the control algorithms, the control loop displays, and control related functions (e.g., Auto Enable, etc.).
There are four Controller Modules (CON0-3) that can be configured separately, one for each control loop display. The number of control
loops provided by a controller is model number dependent.

Table 5-9. Controller Modules (CON0-3)

Title
Control Alarm Mode
Definition
This parameter specifies the Alarm action (PA1
& PA2) of the two Alarm Limits (PL1 & PL2):
0 - H/L PA1: High when PV> PL1
PA2: Low when PV< PL2
1 - OFF - None
2 - H/- PA1: High when PV> PL1
PA2: not affected
3 - -/L PA1: not affected
PA2: Low when PV< PL1
4 - H/HH
PA1: High when PV> PL1
PA2: Hi-Hi when PV> PL2
5 - L/LL PA1: Low when PV< PL1
PA2: Lo-Lo when PV< PL2
6 - DEV PA1: Hi-Dev when Dev > PL1
PA2: Lo-Dev when Dev < PL2
(Examples are in the cell that follows.)
Atom CON0 CON1 CON2 CON3
AIX B335 B340 B345
(0-3)
1 of 9
Default
B350 1
