Digilent Genesys ZU Reference Manual page 28

Pin
Function
Number
MIPI D‐PHY Lane 1
5
(‐)
MIPI D‐PHY Lane 1
6
(+)
7 GND
8 MIPI D‐PHY Clock (‐) C onnected to a 1.2V VCCO HP bank
MIPI D‐PHY Clock
9
(+)
10 GND
11 GPIO/Power enable Connected to a 1.2V VCCO HP bank via a 3.3V level‐translator
GPIO/Clock
12
feedback
13 SCL
14 SDA
15 3V3
Pcam modules are connected to the Pcam host port using a flexible flat cable (FFC). To connect the cable
to the Genesys ZU follow these instructions:
Locate the Pcam connector.
Pull directly up on the white colored tab to open the connector.
Insert the FFC with the contacts facing the left edge, away from the center of the Genesys ZU.
Ensure the FFC is fully inserted.
Gently press down on both sides of the white colored tab to latch the FFC into the connector.
The FFC is now connected properly.
Genesys ZU Implementation
Connected to a 1.2V VCCO HP bank
Connected to a 1.2V VCCO HP bank
GND
Connected to a 1.2V VCCO HP bank
GND
N/C
Connects to branch 0 (MIPI A) and branch 1 (MIPI B) of the main I2C bus
multiplexer
Connects to branch 0 (MIPI A) and branch 1 (MIPI B) of the main I2C bus
multiplexer
3.3 V Power rail
