modules can be used. The primary use case is Linux OS, so modules with Linux drivers available in‐kernel
are recommended. For WWAN radio modules a SIM slot is present on the bottom side of the board.
6. Peripheral Connectivity
6.1. USB Full‐Featured Type‐C
USB 3.1 Gen1 and USB 2.0 support is handled by the Full‐Featured Type‐C receptacle J6. The connector
has a USB 2.0 pair for backward compatibility, one high‐speed transceiver lane (two pairs) for USB 3.1,
and configuration channel (CC). Since the plug is reversible, the upper and lower rows double the
number of pins for each function, designated by suffixes 1 and 2. Plug orientation is established during
the configuration process over the CC1 and CC2 pins. Depending on the orientation, either pins with
suffix 1 or pins with suffix 2 carry actual signals. Multiplexing 1 and 2 for the USB 3.1 lane is done by an
on‐board hardware multiplexer.
Unlike the other USB connector types, Type‐C does not inherently establish the relationship of host and
device ports. This relationship is determined during the same configuration process.
On the Genesys ZU, data behavior is Dual‐Role‐Data (DRD), ie. can behave either as a Downstream‐
Facing Port (DFP) or an Upstream‐Facing Port (UFP), depending on the connected partner and MPSoC
configuration. Power behavior is Dual‐Role‐Power (DRP), but even if UFP is negotiated, the board
remains self‐powered. In DFP role the advertised current capability and limit is 0.9 A with the possibility
of increasing it to 1.5 A. USB Power Delivery is not supported.
Management of the Type‐C port is handled by a companion chip, the TI TUSB322I. It handles
attachment, cable orientation, role detection and current advertisment. It connects to the main I2C bus
of the board and can be used to read status and set port roles for Type‐C. It responds to address
1000111b on branch 3 of the I2C multiplexer.
The USB 2.0 pair is implemented by a Microchip USB3320 PHY interfacing with the PS‐side controller of
MPSoC over ULPI. The USB 3.1 lane is implemented using a PS‐GTR transceiver lane.
In the box you can find a USB Type‐C Legacy Adapter reference as CAR3G1‐3 in the Type‐C specifications.
It has a Full‐Featured Type‐C plug on one end and a USB 3.1 Standard‐A receptacle on the other. Use it
to connect non‐Type‐C USB 2.0 or USB 3.1 devices to the Genesys ZU.
6.2. USB 2.0 Host
Host‐only USB 2.0 functionality is implemented by a Microchip USB3320 PHY and a Microchip USB2513B
hub. The PHY is wired to the PS‐side controller of MPSoC over ULPI. The hub has three Downstream‐
Facing Ports. Two of these connect to a dual‐stacked Type‐A connector, providing 0.5A current per port.
