PIC32 TQFP64

Figure 9-31: Connection schematic for
64-pin TQFP MCU via 2x5 male header
RE5
RE6
RE7
RG6
RG7
RG8
MCLR
RG9
VSS
PIC32MX534F064H
VDD
RB5
RB4
RB3
RB2
RB1
RB0
MCU-VCC VCC
MCU- RB6/PGC
MCU- RB7/PGD
MCU-MCLR
SOSCO
SOSCI
RD0
On-board
RD11
2x5 connector
RD10
RD9
RD8
VSS
OSC2
OSC1
VDD
D+/RG2
D-/RG3
VUSB
VBUS
USB-ID
Page 40
PGC- RB6
USER
PGD- RB7
INTERFACE
MCLR
