PIC DIP28

Figure 9-5: Connection schematic for
28-pin DIP MCU via 2x5 male header
100nF
1K
MCLR RB7
RB6
RA0
RB5
RA1
RB4
RA2
RA3 RB3
RA4 RB2
RA5 RB1
GND RB0
VCC
OSC1
GND
OSC2
RC0 RC7
RC1 RC6
RC2 RC5
RC4
RC3
28 PIN
MCU-VCC VCC
PGC- RB6
MCU- RB6/ PGC
MCU- RB7/ PGD PGD- RB7
USER
INTERFACE
MCU-MCLR
MCLR
On-board
2x5 male
connector

PIC DIP40

Figure 9-6: Connection schematic for
40-pin DIP MCU via 2x5 male header
MCLR RB7
RA0 RB6
RA1 RB5
RA2 RB4
RA3
RB3
RA4 RB2
RA5 RB1
RE0 RB0
RE1 VCC
RE2
GND
VCC
RD7
GND RD6
OSC1 RD5
OSC2 RD4
RC0 RC7
RC6
RC1
RC2 RC5
RC3 RC4
RD0 RD3
RD1 RD2
40 PIN
Page 21
100nF
MCU-VCC VCC
1K
MCU- RB6/ PGC PGC- RB6
MCU- RB6/ PGD PGD- RB7
MCU-MCLR MCLR
On-board
2x5 male
connector
USER
INTERFACE
