Installation Instruction Booklet Information
The entire Endless Pool system is ETL listed, Ref. #2001779 and conforms to UL Standard #1563. Individually, all electrical
components of the Endless Pool are UL and/or CSA approved. As defined by the International Residential Code (IRC), the Endless
Pool is considered an above-ground or an in-ground pool depending on the installation. That is to say, customers can install our
Endless Pool Kit above-ground on a garage or basement floor or in the backyard or they can sink it partially or fully in-ground. The
unit is completely self-supporting. As required by the IRC the Endless Pool meets all the following standards: ANSI/NSPI Standards
#3 (Permanently Installed Residential Spas), #4 (Above-ground/On-ground Residential Swimming Pools), #5 (Residential In-ground
Swimming Pools), and #6 (Portable Spas). The appropriate governing standard is dependent on the installation method and the
requirements and definitions used by the local governing bodies.
All electrical connections should be made by a licensed electrician in accordance with the current national and local electrical codes.
Please read this Owner's Manual and all associated Supplemental Guides prior to beginning your project.
Installation Instructions Table of Contents
Warnings and Safety Information . . . . . . . . . . . . . . . . . . . . . 1
Pool Arrival and Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Panel Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Equipment Cabinet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Aluminum Skirting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Liner Hanger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Liner Underlayment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Corner Steps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Foam Corners . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Thru-wall Connections Part 1 . . . . . . . . . . . . . . . . . . . . . . . 15
Liner Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Propulsion System Part 1 . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Plumbing Part 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Thru-wall Connections Part 2 . . . . . . . . . . . . . . . . . . . . . . 21
Plumbing Part 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Propulsion System Part 2 . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Coping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Cover System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Outdoor Installations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Heater-Controller Plug-In Connections . . . . . . . . . . . . . . . 35
Electrical Wiring Connections - 60Hz (US) . . . . . . . . . . . 36
Electrical Wiring Connections - 50Hz (International) . . . . . . 37
Pool Start Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Finishing Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Product Information Label . . . . . . . . . . . . . . . . . . . . . . . . . 40
Product Installation Information . . . . . . . . . . . . . . . . . . . . 40
Suction Outlet Fitting Service Instructions . . . . . . . . . . . . 40
