Locking Strap Installation
Make sure the cover is in the closed position prior to installing
the safety strap. Locate the center of the leading edge. The ideal
location for the safety strap should be no more than 6" (15cm)
away from the center point of the leading edge in either direc-
tion. Drill a 5/16" (8mm) hole 3/4" (19mm) above the leading
edge flange. Insert the rubber well nut into the drilled hole.
Using one of the small middle grommets in the safety strap,
insert the washer and 8-32 x 1" (25mm) screw into the rubber
well nut Fig 90.
Leading
Edge
Fig. 90
Pull the safety strap onto the rear aluminum coping section to
the desired anchor location (large grommet in safety strap) and
mark the anchor location. The anchor location should be no
more than 6" (15cm) away from the center point of the leading
edge in either direction to avoid the panel stiffeners on the back
side of the rear pool panel.
Drill a 5/8" (16mm) hole through the aluminum coping and
top flange of the pool panel in the anchor location. Place the
anchor housing into the drilled hole. Place the anchor pin
through the large grommet in the safety strap and into the
anchor housing. This should lock the pin in place. Use the pro-
vided key to remove the anchor pin Fig 91.
Fig. 91
Screw
Washer
Safety
Strap
Well Nut

Outdoor Installations

For outdoor installations, place the cover pump on top of the
cover. Attach a garden hose to the water outlet and leave the
pump plugged into a GFCI outlet. The pump will turn itself on
automatically when the level of water on the cover is sufficient
to satisfy the internal float level.
