UG-1759 ADMV4530IQ-EVALZ/ADMV4530IF-EVALZ

ORDERING INFORMATION

BILL OF MATERIALS

The ADMV4530IQ-EVALZ bill of materials is identical to the ADMV4530IF-EVALZ except for one row (see Note 1 of Table 2).
Table 2. ADMV4530IQ-EVALZ
Quantity Reference Designator
5 5V, VCC_1.8V, VCC_3.3V,
VCC_3.3V_VCO, VCC_4.0V
1 C1
14 C11 to C24
1 C2
1 C3
3 C50 to C52
1 C55
1 C60
8 C61 to C68
1 C69
2 C70, C71
2 C72, C73
5 GND1 to GND5
1 RFOUT
2 IF_GAIN_TP, RF_GAIN_TP
6 IN, IP, QN, QP, REF_IN, VSUPPLY
1 P1
1 P2
2 R1, R2
20 R3, R4, R11 to R25, R28 to R30
2 R26, R27
3 R41 to R43
1 R44
2 R45, R50
2 R46, R47
1 R49
4 R51 to R54
3 R61 to R63
1 S1
1 U1
1 U2
1 U3
1 U4
1 U5
1 U6
20 C5, C31 to C44, C80 to C84
1 C4
1 C53
1 C54
3 EXT_VT, IF_GAIN, RF_GAIN
1 R31
1 R48
1 R5
1 For the ADMV4530IF-EVALZ, only REF_IN and VSUPPLY are applicable for this row.
Description
Test points, red
Capacitor, 150 pF, 50 V, 5%, 0402
Capacitors, 1 μF, 16 V, 10%, 0402
Capacitor, 15 nF, 35 V, 10%, 0402
Capacitor, 20 pF, 16 V, 5%, 0402
Capacitors, 0.1 μF, 16 V, 10%, 0402
Capacitor, 10 μF, 6.3 V, 20%, 0402
Capacitor, 0.01 μF, 50 V, 10%, 0402
Capacitors, 10 μF, 16 V, 10%, 0603
Capacitor, 1 nF, 50 V, 5%, 0603
Capacitors, 1 nF, 50 V, 5%, 0402
Capacitors, 1 μF, 16 V, 10%, 0603
Test points, black
Connector, 2.92 mm, 40 GHz
Test points, orange
1 Connectors, edge launch, SMA
Connector, vertical, surface-mount
technology (SMT), 120-pin
Connector, vertical, header, 10-pin
Resistors, 910 Ω, 1/16 W, 0.1%, 0402
Resistors, 0 Ω, 1/10 W, 0402
Resistors, 0 Ω, 1/10 W, 0603
Resistors, 1.1 kΩ, 1/16 W, 1%, 0402
Resistor, 680 Ω, 1/16 W, 0.1%, 0402
Resistors, 10 kΩ, 1/10 W, 1%, 0402
Resistors, 100 kΩ, 1/16 W, 1%, 0402
Resistor, 2.1 kΩ, 1/16 W, 1%, 0402
Resistors, 33 Ω, 1/10 W, 5%, 0402
Resistors, 330 Ω, 1/16 W, 5%, 0402
Switch, mechanical, push button
IC, Ka band upconverter
IC, LDO regulator, 1.8 V
IC, LDO regulator, 3.3 V
IC, LDO regulator, 3.3 V
IC, LDO regulator, 3.3 V
2
IC, 24LC32A, EEPROM, I C
Capacitors, 0402, do not install (DNI)
Capacitor, 20 pF, 16 V, 5%, 0402, DNI
Capacitor, 1 nF, 50 V, 5%, 0402, DNI
Capacitor, 4.7 μF, 16 V, 10%, 0603, DNI
Connectors, edge launch, SMA, DNI
Resistor, 0 Ω, 1/10 W, 0402, DNI
Resistor, 0402, DNI
Resistor, 100 kΩ, 1/16 W, 0402, DNI
Rev. A | Page 20 of 21
Evaluation Board User Guide
Manufacturer
Components Corporation
Murata
Yageo
TDK
AVX Corporation
Kemet
Samsung
Murata
Murata
Murata
Murata
TDK
Components Corporation
Hirose Electric Co.
Components Corporation
Cinch Connectivity
Hirose Electric Co.
Harwin Inc.
Panasonic
Panasonic
Panasonic
Yageo
Panasonic
Panasonic
Panasonic
Panasonic
Panasonic
Panasonic
Omron Electronics Inc.
Analog Devices
Analog Devices
Analog Devices
Analog Devices
Analog Devices
Microchip Technology
Not applicable
AVX Corporation
Murata
TDK
Cinch Connectivity
Panasonic
Not applicable
Panasonic
Part Number
TP-104-01-02
GRM1555C1H151JA01D
CC0402KRX5R7BB105
CGA2B3X7R1V153K050BB
0402YA200JAT2A
C0402C104K4RACTU
CL05A106MQ5NUNC
GCM155R71H103KA55D
GRM188R61C106KAALD
GRM1885C1H102JA01D
GRM1555C1H102JA01
CGA3E1X7R1C105K080AC
TP-104-01-00
HK-LR-SR2(12)
TP-104-01-03
142-0701-851
FX8-120S-SV(21)
M20-9980546
ERA-2AEB911X
ERJ-2GE0R00X
ERJ-3GEY0R00V
RC0402FR-071K1L
ERA-2ARB681X
ERJ-2RKF1002X
ERJ-2RKF1003X
ERJ-2RKF2101X
ERJ-2GEJ330X
ERJ-2GEJ331X
B3S1000
ADMV4530ACCZ
ADM7170ACPZ-1.8-R7
ADM7171ACPZ-3.3-R7
ADM7170ACPZ-3.3-R7
ADM7154ARDZ-3.3-R7
24LC32A-I/MS
Not applicable
0402YA200JAT2A
GRM1555C1H102JA01
C1608X5R1C475K080AC
142-0701-851
ERJ-2GE0R00X
Not applicable
ERJ-2RKF1003X
