3.4 Add and Remove route points

Add Point
To Add a new route point, click on the nearest point on the route summary, and you will see this section of
your route on the detail map. Next pan around the detail map, by pressing the left mouse key whilst moving
the cursor around to find the exact place where you wish to insert a new route point. If necessary
click on the + - zoom button on the detail map to see the position more clearly. Once you have
found the place where you wish to Add a new point, double click the left mouse key to centre on
the + -
this new point, and then press Insert and you will see a new point inserted at this location.
Remove Point
To delete a point, click on the point in the route summary so that the point is highlighted, and then press
the Delete key. Note, you may need to press the zoom button to see the points more clearly.
Zoom Route summary
If you click on the zoom button you will see a portion of the Route Summary in much more detail. This will
be centred on the point you are currently reviewing. Note you can see the direction of travel by the yellow
trail which shows the direction of the previous point. Just click on the zoom button again to go back to the
full route summary. The length of the yellow trail shows the warning distance, so short tail indicates 50m
warning distance and long tail indicates 1000m etc.
