3.5 Point Setup

Whether points have been added using the hand held event marker or by adding points as detailed above,
you will now need to provide instructions for the Driver which will appear on the OLED display. These
instructions include an icon which will appear on the OLED, such as a left turn or a roundabout sign and also
the warning distance before the driver should make the turn.
Select the first point, either by clicking on it on the route summary or by clicking on the up or down arrow in
the selected point screen, until you see Selected Point 1.
Click up or down to
move to next or
previous point.
The first point should always be setup as a start point as shown. This can be selected by clicking on the arrow
beside the Point set-up Instruction box, as shown below. Next you should setup the warning distance, so
that the driver is warned, this set distance before arriving at the actual the point. You can choose between
50m, 100m, 250m, 500m and 1000m.
When you have completed setting up the point, you will note that the point in the route summary now
shows green. To move on to the next point click the down arrow in the selected point box.
