Connectors

This section describes the pinouts for each of the five connectors on the XVME-973.

P1 Connector

P1 connects up to two 3.5-inch hard drives. Power for the drives is not supplied by the
XVME-973.
The total cable length must not exceed 18 inches. Also, if two drives are
connected, they must be no more than six inches apart.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Chapter 6 – XVME-973 Drive Adapter Module
Pin Signal Pin
1 HDRESET* 21 NC
2 GND 22 GND
3 HD7 23 DIOW*
4 HD8 24 GND
5 HD6 25 DIOR*
6 HD9 26 GND
7 HD5 27 IORDY
8 HD10 28 ALE
9 HD4 29 NC
10 HD11 30 GND
11 HD3 31 IRQ14
12 HD12 32 IOCS16*
13 HD2 33 DA1
14 HD13 34 NC
15 HD1 35 DA0
16 HD14 36 DA2
17 HD0 37 CS1P*
18 HD15 38 CS3P*
19 GND 39 IDEATP*
20 NC 40 GND
Caution
Signal
