- Page 6 The Appendices are designed to introduce and reinforce a variety of module-related Architecture, backplane signal/pin descrip- topics including: XYCOM’s Standard tions, a block diagram and schematics, and a quick reference section. 1.3 MODULE OPERATIONAL DESCRIPTION Figure l- 1 shows an operational block diagram of the DIO module.
-
Page 8: Specifications
I/O modules. The central core of the XYCOM Standard I/O Architecture is the “kernel”. uses a non-intelligent kernel which provides the circuitry required to receive and generate all of the signals for a VMEbus defined 16-bit "slave”... - Page 9 XVME-240 Manual October, 1984 Table l-l. DIO Module Specifications Specification Characteristic 64 (arranged in 8 logical ports) Number of I/O Channels Number of Flag Output Lines Number of Interrupt Input Lines Output Characteristics - Flag Outputs: Vol Low-level output voltage 0.5V max.
- Page 10 XVME-240 Manual October, 1984 Table l-1. DIO Module Specifications (continued) Specification Characteristic Temperature Operating Non-Operating Humidity 5 to 95% RH non-condensing (Note, extreme low humidity conditions may require special protection against static discharge.) Altitude Sea-level to 10,000 ft. (3048m) Operating Sea-level to 50,000 ft.
-
Page 11: Installation
DIO; and a controller subsystem module which employs a Data Transfer Bus Arbiter, a Subsystem Clock driver, a System Reset driver, and a Bus time- out module. (The XYCOM XVME-010 System Resource Module provides a controller subsystem with the components listed.) - Page 13 Interface Block). The base address decoding scheme for XYCOM I/O modules is such that the starting address for each I/O Interface Block resides on a 1K boundary. Thus the module base address may be set to any one of 64 possible 1K boundaries within the Short I/O Address space.
- Page 16 XVME-240 Manual October, 1984 2.4.2 Address Space Selection The user is given the option of placing the DIO in VMEbus Short I/O or Standard Memory Space. The selection is made by configuring jumper J2 and Switch 8 of Switch Bank 2 (see Figure 2-3) as shown in Table 2-3 below.
- Page 17 XVME-240 Manual October, 1984 2.4.3 Supervisor/Non-Privileged Mode Selection The DIO can be configured to respond to only Supervisory access, or to both Non- Privileged and Supervisory accesses, by selecting the position of Switch 7 (located in Switch Bank 2, see Figure 2-3), as shown in Table 2-4 below.
- Page 18 XVME-240 Manual October, 1984 2.4.5 IACKIN*/IACKOUT* Daisy Chain The DIO has the ability to generate a VMEbus interrupt. Therefore, jumper Jl is hardwired in position “ B " to enable the IACKIN*/IACKOUT* daisy chain. CAUTION The jumper shorting IACKIN* to IACKOUT* for the DIO’s slot in the backplane must be removed, or the...
- Page 19 XVME-240 Manual October, 1984 Table 2-6. Interrupt Level Options Switches Level No Level selected Level 1 Level 2 Level 3 Level 4 Level 5 Level 6 Level 7 N O T E Open = "1" Logic Closed = Logic "0"...
- Page 20 XVME-240 Manual Octo ber , 1984 Jumpers J3-J10 are all two position jumpers, with the two positions labeled " A " and "B" . Figure 2-5 shows an enlarged view of jumper Jl0 and how the two positions are labeled. The remaining 7 jumpers are all identical to jumper Jl0.
