RJ-45 10/100 Base-T Connector

Table Chapter 7 -4 details the pinout for the Base-T connector.
Table Chapter 7 -5 details the pinout for the SCSI connector.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Chapter 7 – XVME-978/2 PCI Ethernet/SCSI Controller Module
Table Chapter 7 -4. RJ-45 10/100 Base-T Connector Pinout
Pin Signal
1 TX+
2 TX-
3 RX+
4
5
6 RX-
7
8
Table Chapter 7 -5. SCSI Connector Pinout
Pin Signal Pin
1 GND 35
2 GND 36
3 GND 37
4 GND 38
5 GND 39
6 GND 40
7 GND 41
8 GND 42
9 GND 43
10 GND 44
11 GND 45
12 GND 46
13 GND 47
14 GND 48
15 GND 49
16 GND 50
17 TRMPWR 51
18 TRMPWR 52
19 NC 53
20 GND 54
21 GND 55
22 GND 56
23 GND 57
24 GND 58
25 GND 59
26 GND 60
27 GND 61
28 GND 62
29 GND 63
30 GND 64
31 GND 65
32 GND 66
33 GND 67
34 GND 68
Signal
SCD12
SCD13
SCD14
SCD15
SCDPH
SCD0
SCD1
SCD2
SCD3
SCD4
SCD5
SCD6
SCD7
SCDPL
GND
GND
TRMPWR
TRMPWR
NC
GND
SATN*
GND
SBSY*
SACK*
SRST*
SMSG*
SSEL*
S_CD*
SREQ*
SIO*
SCD8
SCD9
SCD10
SCD11
7-7
