Interboard Connector 2 (P6)

Table Chapter 7 -3 details the pinout for interboard connector 2.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Chapter 7 – XVME-978/2 PCI Ethernet/SCSI Controller Module
Table Chapter 7 -3. Interboard Connector 2 Pinout
Pin Signal
1 TCLK
2 TRST*
3 TMS
4 TDO
5 TDI
6 PCI-RSVD9A (pn2-8)
7 PCI-RSVD10B (pn2-9)
8 PCI-RSVD11A (pn2-10)
9 PCI-RSVD14A (pn1-12)
10 PCI-RSVD14B (pn1-10)
11 PCI-RSVD19A (pn2-17)
12 PMC-RSVD (pn2-34)
13 PMC-RSVD (pn2-52)
14 PMC-RSVD (pn2-54)
15 PCICLK3 (NC)
16 PIRQA*
17 PIRQB*
18 PIRQC*
19 PIRQD*
20 REQ3*
21 PCICLK2 (NC)
22 REQ1*
23 GNT3*
24 PCICLK1
25 GNT1*
26 PCIRST*
27 PCICLK0
28 GNT0*
29 REQ0*
30 REQ2*
31 AD(31)
32 AD(30)
33 AD(29)
34 AD(28)
35 AD(27)
36 AD(26)
37 AD(25)
38 AD(24)
39 BE3*
40 GNT2*
Pin Signal
41 AD(23)
42 AD(22)
43 AD(21)
44 AD(20)
45 AD(19)
46 AD(18)
47 AD(17)
48 AD(16)
49 BE2*
50 FRAME*
51 IRDY*
52 TRDY*
53 DEVSEL*
54 STOP*
55 PLOCK*
56 PERR*
57 SDONE
58 SBO*
59 SERR*
60 PAR
61 BE1*
62 AD(15)
63 AD(14)
64 AD(13)
65 AD(12)
66 AD(11)
67 AD(10)
68 AD(9)
69 AD(8)
70 BE0*
71 AD(7)
72 AD(6)
73 AD(5)
74 AD(4)
75 AD(3)
76 AD(2)
77 AD(1)
78 AD(0)
79 ACK64*
80 REQ64*
