Xycom XVME-655 Manual page 85

Appendix C – Video Modes
Table C-1 describes S3 Video BIOS support of standard VGA text and graphics.
Mode S3 Mode Display
(Hex) Mode
00 Std VGA Text
00* Std VGA Text
00+ Std VGA Text
01 Std VGA Text
01* Std VGA Text
01+ Std VGA Text
02 Std VGA Text
02* Std VGA Text
02+ Std VGA Text
03 Std VGA Text
03* Std VGA Text
03+ Std VGA Text
04 Std VGA Graph
05 Std VGA Graph
06 Std VGA Graph
07 Std VGA Text
07+ Std VGA Text
0D Std VGA Graph
0E Std VGA Graph
0F Std VGA Graph
10 Std VGA Graph
11 Std VGA Graph
12 Std VGA Graph
13 Std VGA Graph
© Copyright 1996 S3 Incorporated
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Table C-1. Standard VGA Modes
Screen Colors Buffer
Resolution Start
40x25 Chars b/w B8000
40x25 Chars b/w B8000
40x25 Chars b/w B8000
40x25 Chars 16 B8000
40x25 Chars 16 B8000
40x25 Chars 16 B8000
80x25 Chars b/w B8000
80x25 Chars b/w B8000
80x25 Chars b/w B8000
80x25 Chars 16 B8000
80x25 Chars 16 B8000
80x25 Chars 16 B8000
320x200 4 B8000
320x200 4 B8000
640x200 2 B8000
80x25 Chars Mono B0000
80x25 Chars Mono B0000
320x200 16 A0000
640x200 16 A0000
640x350 Mono A0000
640x350 16 A0000
640x480 2 A0000
640x480 16 A0000
320x200 256 A0000
Note: b/w = black and white
©
Sweep/Refresh Dot Clock (MHz)
Rate
31.5KHz/70Hz 25.175
31.5KHz/70Hz 25.175
31.5KHz/70Hz 28.322
31.5KHz/70Hz 25.175
31.5KHz/70Hz 25.175
31.5KHz/70Hz 28.322
31.5KHz/70Hz 25.175
31.5KHz/70Hz 25.175
31.5KHz/70Hz 28.322
31.5KHz/70Hz 25.175
31.5KHz/70Hz 25.175
31.5KHz/70Hz 28.322
31.5KHz/70Hz 25.175
31.5KHz/70Hz 25.175
31.5KHz/70Hz 25.175
31.5KHz/70Hz 28.322
31.5KHz/70Hz 28.322
31.5KHz/70Hz 25.175
31.5KHz/70Hz 25.175
31.5KHz/70Hz 25.175
31.5KHz/70Hz 25.175
31.5KHz/60Hz 25.175
31.5KHz/60Hz 25.175
31.5KHz/70Hz 25.175
C-1
