P3 Connector

P3 connects a single 3.5-inch floppy drive. Only one drive is supported. Power for this
drive is not supplied by the XVME-973.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Chapter 6 – XVME-973 Drive Adapter Module
Pin Signal Pin
1 GND 18
2 FRWC* 19
3 GND 20
4 NC 21
5 KEY (NC) 22
6 NC 23
7 GND 24
8 IDX* 25
9 GND 26
10 MO1* 27
11 GND 28
12 NC 29
13 GND 30
14 FDS1* 31
15 GND 32
16 NC 33
17 GND 34
Signal
FDIRC*
GND
FSTEP*
GND
FWD*
GND
FWE*
GND
FTK0*
GND
FWP*
GND
FRDD*
GND
FHS*
GND
DCHG*
6-4
