VGA Connector
Keyboard Port Connector
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Pin
Signal
1
RED
2
GREEN
3
BLUE
4
NC
5
GND
6
GND
7
GND
8
GND
9
KEY
10
GND
11
NC
12
DDC.ID
13
HYSNC
14
VSYNC
15
NC
Pin
Signal
1
DATA
2
NC
3
GND
4
+5V
5
CLK
6
NC
Chapter 2 – Installation
2-6
