Chapter 5 – XVME-978 PCI Ethernet Controller Module
A high-performance 32-bit PCI bus mastering Ethernet controller may be added to the
XVME-655 via the XVME-978 Ethernet Controller. The XVME-978 features a NE2100
and NE1500 software-compatible Ethernet interface with support for both 10BaseT and
10Base2 connections. The XVME-978 is designed to mate with the two interboard
connectors. It also provides a second set of connectors to allow the installation of an
XVME-976 which offers PMC and PC/104 sites.
Architectural Block Diagram
Figure Chapter 5 -1 illustrates the XVME-978 block diagram.
Interboard Connector 1 (P5)
Installation
Figure Chapter 5 -2 illustrates how the XVME-978 module connects to the XVME-655
processor module.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Interboard Connector 2 (P3)
PCI Bus
PCI Ethernet
AM 79C970
10BaseT
10Base2
ISA Bus
Interboard Connector 1 (P6)
Note: Used for addition of 3rd board
Figure Chapter 5 -1. XVME-978 Block Diagram
Interboard Connector 2 (P4)
5-1
