Xycom XVME-655 Manual page 30

Option
Autotype Fixed Disk
Type
Cylinders
Heads
Sectors/Track
Write Precomp
Multi-Sector Transfers
LBA Mode Control
32-Bit I/O
Transfer Mode
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Description
Reads the hard disk parameters from the drive if you press
sets the Type field to "User" and lets you edit other fields. Do not attempt to
manually set the disk drive parameters unless instructed to do so by Xycom
Application Engineering.
Options are "1 to 39", "User," and "Auto." The "1 to 39" option fills in all
remaining fields with values for predefined disk type. "User" prompts you to
fill in remaining fields. "Auto" autotypes at each boot, displays settings in
setup menus, and does not allow you to edit the remaining fields.
Indicates the number of cylinders on the hard drive. This information is
automatically entered if the Autotype Fixed Disk option is set.
Indicates the number of read/write heads on the hard drive. This information
is automatically entered if the Autotype Fixed Disk option is set.
Indicates the number of sectors per track on the hard drive. This information
is automatically entered if the Autotype Fixed Disk option is set.
This value is not used or required by IDE hard drives.
Options are "Auto," "2," "4," "8," and "16" sectors. "Auto" sets the number of
sectors per block to the highest number supported by the drive.
Enables Logical Block Access (LBA). Default is disabled and should work with
most hard drives.
Enables 32-bit communication between the CPU and IDE interface.
Selects the method for transferring the data between the hard disk and
system memory. Available options are determined by the drive type and cable
length.
Chapter 3 – BIOS Setup Menus
. It then
ENTER
3-4
