Connectors

This section provides the pinouts for the XVME-655 connectors.

Serial Port Connectors

Pin
1
2
3
4
5
6
7
8
9

Parallel Port Connector

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
COM1
Signal
DCD1
RXD1
TXD1
DTR1
GND
DSR1
RTS1
CTS1
RI1
Pin Signal Pin
1 STROBE 14
2 PDOUT0 15
3 PDOUT1 16
4 PDOUT2 17
5 PDOUT3 18
6 PDOUT4 19
7 PDOUT5 20
8 PDOUT6 21
9 PDOUT7 22
10 PACK 23
11 PBUSY 24
12 PE 25
13 SELECT
Chapter 2 – Installation
COM2
Pin Signal
1 DCD2
2 RXD2
3 TXD2
4 DTR2
5 GND
6 DSR2
7 RTS2
8 CTS2
9 RI2
Signal
AUTOFEED
PERROR
INIT
SELIN
GND
GND
GND
GND
GND
GND
GND
GND
2-5
