VMEbus Connectors

P1 and P2 are the VMEbus connectors.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
P1 Connector
Pin A B
1 D00 BBBUSY
2 D01 BCLR*
3 D02 ACFAIL*
4 D03 BG0IN*
5 D04 BG0OUT*
6 D05 BG1IN*
7 D06 BG1OUT*
8 D07 BG2IN*
9 GND BG2OUT*
10 SYSCLK BG3IN*
11 GND BG3OUT
12 DS1* BR0*
13 DS0* BR1*
14 WRITE* BR2*
15 GND BR3*
16 DTACK* AM0
17 GND AM1
18 AS* AM2
19 GND AM3
20 IACK* GND
21 IACKIN* NC
22 IACKOUT* NC
23 AM4 GND
24 A07 IRQ7*
25 A06 IRQ6*
26 A05 IRQ5*
27 A04 IRQ4*
28 A03 IRQ3*
29 A02 IRQ2*
30 A01 IRQ1*
31 -12V NC
32 +5V +5V
Chapter 2 – Installation
C
D08
D09
D10
D11
D12
D13
D14
D15
GND
SYSFAIL*
BERR*
SYSRESET
LWORD*
AM5
A23
A22
A21
A20
A19
A18
A17
A16
A15
A14
A13
A12
A11
A10
A09
A08
+12V
+5V
