Display

The display is located in the centre of the control panel. The main screen variants are presented
below.
RPM display mode
Switching between RPM and RCF display mode
SPEED
RCF
TIME
TEMP
PRG
11944
PARA
MENU
rotor speed
centrifugal force
centrifuging time
temperature
program no.
rotor no.
parameters of the centrifuge
configuration menu
After switching on centrifuge, welcome screen
appears. After the welcome screen disappears it is
possible to setting up parameters.
Simplified display mode is set as default, there is
possible to switch to normal (see chapter 9.3)
display mode (with two sub modes shown below).
Normal display
For normal display switching between RPM and
RCF display mode may be obtain by pressing and
keeping key by 1s :
then one should choose demand mode.
© 2018 Corning Incorporated
20
o
RCF display mode
assigned/measured
assigned/measured
assigned/measured
assigned/measured
