6 Centrifugation

Power switching ON/OFF is carried out with master switch situated on the right-side wall of the
centrifuge. All settings on the centrifuge are done by means of the control panel.

Control panel

The control panel placed on the front casing serves the purpose of controlling centrifuge
operation.
SHORT 1
START
STOP 2
COVER
FAST
COOL
BACK
RPM/RCF
UP
DOWN
LEFT
RIGHT
SET SET
1 the centrifuge is working as long as the key is pressed
2
First-time pressing will make stopping centrifuging with acceleration characteristics set in the current
program; second-time pressing will make braking as fast as possible.
Control panel
short-time centrifuging
start centrifugation run
end centrifugation run
cover opening
start fast cooling mode
exit the current menu / cancelling
switching between rpm display mode and rcf display mode
navigation in menu / increasing values
navigation in menu / decreasing values
navigation in menu
navigation in menu
changing parameters / confirming changes
19
