Rational iCombi Pro Original Installation Instructions page 57

6-1/1 G (1 NAC 230 V)
6-2/1 G (1 NAC 230 V)
10-1/1 G (1 NAC 230 V)
10-2/1 G (1 NAC 230 V)
20-1/1 G (1 NAC 230 V)
20-2/1 G (1 NAC 230 V)
6-1/1 G (1 NAC 240 V)
6-2/1 G (1 NAC 240 V)
10-1/1 G (1 NAC 240 V)
10-2/1 G (1 NAC 240 V)
20-1/1 G (1 NAC 240 V)
20-2/1 G (1 NAC 240 V)
6-1/1 G (2 AC 200 V)
6-2/1 G (2 AC 200 V)
10-1/1 G (2 AC 200 V)
10-2/1 G (2 AC 200 V)
20-1/1 G (2 AC 200 V)
20-2/1 G (2 AC 200 V)
6-1/1 G (2 AC 208 V)
6-2/1 G (2 AC 208 V)
10-1/1 G (2 AC 208 V)
10-2/1 G (2 AC 208 V)
20-1/1 G (2 AC 208 V)
20-2/1 G (2 AC 208 V)
6-1/1 G (2 AC 220 V)
6-2/1 G (2 AC 220 V)
10-1/1 G (2 AC 220 V)
10-2/1 G (2 AC 220 V)
80.06.083_iCombi Pro-iCombi Classic_IM_V01_en-US
Hz Power con-
sumption
(A)
50/60 2.6
50/60 3.9
50/60 4
50/60 6.3
50/60 5.7
50/60 9.3
Hz Power con-
sumption
(A)
50/60 2.5
50/60 3.8
50/60 3.8
50/60 6.1
50/60 5.4
50/60 9
Hz Power con-
sumption
(A)
50/60 1.9
50/60 3.3
50/60 3.8
50/60 6.3
50/60 6.0
50/60 9.5
Hz Power con-
sumption
(A)
60 2.9
60 4.3
60 4.3
60 7.2
60 6.3
60 10.6
Hz Power con-
sumption
(A)
50/60 2.7
50/60 4.1
50/60 4.1
50/60 6.8
6 | Electrical connection
Power (kW) Fuse (A)
0.6 15
0.9 15
0.91 15
1.46 15
1.3 15
2.15 15
Power (kW) Fuse (A)
0.6 15
0.9 15
0.91 15
1.46 15
1.3 15
2.15 15
Power (kW) Fuse (A)
0.38 15
0.65 15
0.75 15
1.25 15
1.2 15
1.9 15
Power (kW) Fuse (A)
0.6 15
0.9 15
0.9 15
1.5 15
1.3 15
2.2 15
Power (kW) Fuse (A)
0.6 15
0.9 15
0.9 15
1.5 15
RCD model
F
B
B
B
F
B
RCD model
F
B
B
B
F
B
RCD model
B
B
B
B
B
B
RCD model
B
B
B
B
B
B
RCD model
B
B
B
B
57 / 84
