Rational iCombi Pro Original Installation Instructions page 55

6-2/3 (2 AC 240 V)
6-1/1 E (2 AC 240 V)
6-2/3 (3 AC 208 V)
6-1/1 E (3 AC 208 V)
6-2/1 E (3 AC 208 V)
10-1/1 E (3 AC 208 V)
10-2/1 E (3 AC 208 V)
20-1/1 E (3 AC 208 V)
20-2/1 E (3 AC 208 V)
6-2/3 (3 AC 240 V)
6-1/1 E (3 AC 240 V)
6-2/1 E (3 AC 240 V)
10-1/1 E (3 AC 240 V)
10-2/1 E (3 AC 240 V)
20-1/1 E (3 AC 240 V)
20-2/1 E (3 AC 240 V)
6-1/1 E (3 AC 440 V)
6-2/1 E (3 AC 440 V)
10-1/1 E (3 AC 440 V)
10-2/1 E (3 AC 440 V)
20-1/1 E (3 AC 440 V)
20-2/1 E (3 AC 440 V)
6-1/1 E (3 AC 480 V)
6-2/1 E (3 AC 480 V)
10-1/1 E (3 AC 480 V)
10-2/1 E (3 AC 480 V)
20-1/1 E (3 AC 480 V)
20-2/1 E (3 AC 480 V)
80.06.083_iCombi Pro-iCombi Classic_IM_V01_en-US
Hz Power con-
sumption
(A)
50/60 32
50/60 61
Hz Power con-
sumption
(A)
60 15.9
60 30
60 62.2
60 52.5
60 103.8
60 103.3
60 188.5
Hz Power con-
sumption
(A)
50/60 18
50/60 35
50/60 71
50/60 61
50/60 118
50/60 119
50/60 219
Hz Power con-
sumption
(A)
60 14.2
60 29.4
60 24.8
60 49.1
60 48.8
60 89.1
Hz Power con-
sumption
(A)
60 16
60 32
60 27
60 52
60 54
60 96
6 | Electrical connection
Power (kW) Fuse (A)
5.7 35/40
10.8 70
Power (kW) Fuse (A)
5.7 20
10.8 35
22.4 70
18.9 60
37.4 125
37.2 125
67.9 200
Power (kW) Fuse (A)
6.2 20
10.8 40
22.4 80
18.9 70/75
37.4 150
37.2 150
67.9 250
Power (kW) Fuse (A)
10.8 20
22.4 35
18.9 30
37.4 60
37.2 60
67.9 100
Power (kW) Fuse (A)
10.8 25
22.4 40
18.9 35
37.4 70
37.2 70
67.9 125
RCD model
B
B
RCD model
B
B
B
B
B
B
B
RCD model
B
B
B
B
B
B
B
RCD model
B
B
B
B
B
B
RCD model
B
B
B
B
B
B
