ICX35-HWC ♦ Industrial Cellular Gateway
3G/4G LTE

6.2.2 Configuring End Device 1


The IP address of the end device connected to ICX35-1 must match the
IP address configured on the ICX35-1 End Device IP Address field.

The Gateway parameter must match the VPN address for the ICX35-1.

6.2.3 Configuring End Device 2


The IP address of the end device connected to ICX35-2 must match the
IP address configured on the ICX35-2 End Device IP Address field.

The Gateway parameter must match the VPN IP address for the ICX35-2
once connected.

6.2.4 Configuring OpenVPN Parameters

You must now configure OpenVPN parameters on both ICX35-HWC radios.
1 Navigate to Configuration > Advanced.
2 Click on the VPN link.
ProSoft Technology, Inc.
April 21, 2016
ICX35-HWC Tech Notes (Example Configurations)
User Manual
Page 69 of 79
