ProSoft ICX35-HWC User Manual page 28

ICX35-HWC Webpage
User Manual
IPSec
The VPN Tunnel Internet Protocol Security (IPsec) feature consists of protocols
used for authentication and encryption.
The IPSec option from the Client drop-down list displays the following
parameters:
Parameter
Local Identifier
Remote IP
Remote Identifier
Remote Subnet
Pre-shared Key
Page 28 of 79
Description
Specifies the identifier to be used for the local side of the IPsec connection. This is
used during authentication of the tunnel. It is a free-form string, although typically it is a
Fully Qualified Domain Name, or an IP address. Max length is 28.
Note: Use the "@" prefix when the IPSec tunnel is established between two ICX35-
HWC's. Example: @ICX35_local (This may be the local Module Name. If you are
establishing an IPSec tunnel with a network router that supports IPSec, no "@" prefix
is needed)
This parameter specifies the IPsec remote IP.
This parameter specifies the identifier to be used for the remote site of the IPsec
connection. This is used during authentication of the tunnel. It is a free-form string,
although typically, it is a FQDN name, or an IP address. Max length is 28.
Note: Use the "@" prefix when the IPSec tunnel is established between two ICX35-
HWC's. Example: @ICX35_remote (This may be the remote Module Name. If you are
establishing an IPSec tunnel with a network router that supports IPSec, no "@" prefix
is needed)
This parameter specifies the subnet address block on the LAN side of the remote peer.
This parameter must be specified in the CIDR notation (i.e., a number from 1 to 32)
Specifies the pre-shared key that needs to match between both ends of the VPN
tunnel.
