ICX35-HWC Webpage
User Manual
System
Up Time
System Time
Board F/W Version
Serial Number
WAN
Connection Type
Signal Level
Network Registration
Link Time
Disconnect Count
IP
Sent Bytes
Received Bytes
Whitelist
Cellular Data Usage
Current Period
LAN
Connection Status
IP Address
Netmask
Ethernet Address (MAC)
Received Bytes
Sent Bytes
DDNS
VPN
Serial
Page 20 of 79
Description
Amount of time the cellular gateway has been active since the last
power cycle or a reset
Current date and time of the ICX35-HWC
Firmware version of the cellular hardware
Serial number of the ICX35-HWC
The type of connection. For example, GSM
Signal Level of cellular network (dBm)
Registered local cellular network
The number of days, hours, minutes, seconds connected to the
WAN
Indicates the time that the unit has lost communication to a cell
tower and has/is attempting to reconnect back to the cellular
service. It counts each time that the service has disconnected from
the cellular service while the unit is running.
IP address of the ICX35-HWC on the WAN
Number of sent bytes on the WAN port for this connection
Number of received bytes on the WAN port for this connection
Indicates if whitelisting is enabled or disabled
Shows the total number of bytes (sent and received) on an ongoing
basis. This number is reset on the Plan Start Day unless changed
by clicking on the Reset Period Usage button.
Displays the Link status
IP address of the ICX35-HWC on the LAN
Subnet Mask
MAC address of the ICX35-HWC
Total number of bytes received on the Ethernet port
Total number of bytes send on the Ethernet port
Dynamic DNS. This value is set during Advanced Configuration.
Set in Advanced Configuration Settings
Based on Advanced Configuration settings. For example, this
displays a serial status based on selections in Advanced
Configuration.
