ProSoft ICX35-HWC User Manual page 31

ICX35-HWC ♦ Industrial Cellular Gateway
3G/4G LTE
Serial / Encapsulation
Parameter
Port Mode
Baud Rate
Data Bits
Parity
Stop Bits
Protocol
ProSoft Technology, Inc.
April 21, 2016
Description
This parameter sets the scheme for the serial port
(RS-232, RS-485, or RS-422)
Baud rate used on the ICX35-HWC serial port
Number of data bits per character for the serial port
Parity type used on the serial port. None, Odd, Even, Mark, Space.
Number of stop bits per character for the serial port.
This parameter sets the serial encapsulation mode for the gateway:
o
Disabled
o
Generic
o
Modbus RTU
o
Modbus ASCII
o
Modbus RTU to TCP
o
Modbus ASCII to TCP
o
DF1 Full-Duplex (Not available for RS485 port mode)
o
DF1 Radio Modem (Not available for RS485 port mode)
ICX35-HWC Webpage
User Manual
Page 31 of 79
