Hardware Installation
User Manual
5.3

LED Indicators

LED
PWR
ERR
MS (Module Status)
NS (Network Status)
Serial Port LEDs
LED
SER
TX
RX
Page 62 of 79
State Description
Off Power is not connected to the power terminals or
source is insufficient to properly power the device.
Solid Green Power is connected to the power terminals
Off Normal operation
Solid Red A critical error has occurred. Program executable
has failed or has been user-terminated and is no
longer running. Press the Reset button or cycle
power to clear the error.
Off ICX35-HWC is powered off
Solid Green Initialization complete / OK
Blinking Green ICX35-HWC is in the process of configuring
Solid Red Unrecoverable error
Blinking Red Reading config/minor error/No SIM
Off ICX35-HWC is powered off
Solid Green Connected to cellular tower
Blinking Green Attempting to connect to cellular tower
Solid Red Duplicate IP (E/IP) /Non-recoverable network fault
Blinking Red Established connection timeout (E/IP) / Minor
network fault
State Description
Flashing Indicates that data is moving from the serial port to
the WAN port.
Off No activity on the port
Flashing Amber The port is actively transmitting data
Off No Activity on the port
Flashing Green The port is actively receiving data.
ICX35-HWC ♦ Industrial Cellular Gateway
ProSoft Technology, Inc.
April 21, 2016
3G/4G LTE
