ProSoft ICX35-HWC User Manual page 47

ICX35-HWC ♦ Industrial Cellular Gateway
3G/4G LTE
Port Forwarding
Parameter
Application
Protocol
LAN IP Address
From Port Range
To Port Range
When the fields above are complete, click the Add button to load the parameters
into the table. To remove an existing mapping in the table, highlight it and click
Delete.
When complete, click Apply.
ProSoft Technology, Inc.
April 21, 2016
Description
Name of particular mapping
Packet delivery method (TCP, UDP, both)
IP address of the destination LAN device
WAN port range through which data will be forwarded to each
device
LAN device port range listening for forwarded traffic
ICX35-HWC Webpage
User Manual
Page 47 of 79
