US Robotics Instant802 APSDK Administrator's Manual page 210

name
--------------------------------------------------------------------
wlan0bssInternal
wlan0bssGuest
USR5453-AP# get interface brguest
Field Value
-------------------------
type bridge
status up
mac 00:01:02:03:04:02
ip 10.10.56.248
mask 255.255.255.0
Disable Guest Access on VLANs
This example assumes you start with Guest Access "enabled" on VLANs and provides commands to
disable it.
1. Get the current status of Guest Access (it is "up" or enabled initially):
USR5453-AP# get interface brguest status
up
The output for the following commands show that VLANs are configured for the Internal and Guest
interfaces (because both interfaces are VLANs: "brguest" is vlan2222 and "br0" is vlan1111):
USR5453-AP# get bridge-port brguest
Name Interface
-------------------
brguest wlan0
brguest vlan2222
USR5453-AP# get bridge-port br0
Name Interface
---------------
br0 wlan0guest
br0 vlan1111
2. The following series of commands reconfigures the Internal interface to use an Ethernet port (by
setting br0 to eth0), disables Guest Access, and removes the two VLANs.
USR5453-AP# add bridge-port br0 interface eth0
USR5453-AP# set bss wlan0bssGuest status down
USR5453-AP# set bss wlan1bssGuest status down
USR5453-AP# remove bridge-port br0 interface vlan1111
USR5453-AP# remove interface vlan1111
USR5453-AP# remove bridge-port brguest interface vlan2222
USR5453-AP# remove interface vlan2222
USR5453-AP# set interface brguest status down
USR5453-AP# set portal status down
status radio beacon-interface
up wlan0 wlan0
up wlan0 wlan0guest
Professional Access Point
Administrator Guide
mac
00:01:02:03:04:01
00:01:02:03:04:02
Class Structure, Commands, and Examples - 210
