US Robotics Instant802 APSDK Administrator's Manual page 186

Command
set
add
Description
The "set" command allows you to set the field values of existing instances of a class.
set unnamed-class [ with qualifier-field qualifier-value ... to ] field value . . .
The first argument is an unnamed class in the configuration.
After this is an optional qualifier that restricts the set to only some instances. For single-
ton classes (with only one instance) no qualifier is needed. If there is a qualifier, it starts
with the keyword with, then has a sequence of one or more qualifier-field qualifier-
value pairs, and ends with the keyword to. If these are included, then only instances
whose present value of qualifier-field is qualifier-value will be set. The qualifier-value
arguments cannot contain spaces. Therefore, you cannot select instances whose
desired qualifier-value has a space in it.
The rest of the command line contains field-value pairs.
set named-class instance | all [ with qualifier-field qualifier-value ... to ] field value . . .
The first argument is either a named class in the configuration.
The next argument is the name of the instance to set, or the keyword all, which indi-
cates that all instances should be set. Classes with multiple instances can be set con-
secutively in the same command line as shown in Example 4 below. The qualifier-value
arguments cannot contain spaces.
Here are some examples. (Bold text indicates class names, field names, or keywords;
text that is not bold indicates values to which the fields are being set.)
1. set interface wlan0 ssid "Vicky's AP"
set radio all beacon-interval 200
2.
3. set tx-queue wlan0 with queue data0 to aifs 3
4. set tx-queue wlan0 with queue data0 to aifs
burst
0
set bridge-port br0 with interface eth0 to path-cost
5.
Note: For information on interfaces used in this example (such as
see "Understanding Interfaces as Presented in the CLI" on page
The "add" command allows you to add a new instance of a class.
add named-class instance [ field value ... ]
add anonymous-class [ field value ... ]
For example:
add radius-user wally
Professional Access Point
Administrator Guide
7 cwmin
wlan0
190.
Class Structure, Commands, and Examples - 186
15 cwmax 1024
200
br0 eth0
, , or )
