US Robotics USR2249 Quick Installation Manual

22 mbps wireless access point

22 Mbps Wireless Access Point

Quick Installation Guide

Note:

For the most updated information, visit: http://www.usr.com/

support. You can also refer to the User Guide on the U.S. Robotics

Installation CD-ROM for more detailed information.

Prepare for installation

Turn on your desktop or laptop computer. Type your password if you are

prompted to do so.

Note:

Your product number is 2249. It is very important that you have your

serial number written down before you install the 22 Mbps Wireless

Access Point. You can find your serial number on the bottom of the

Wireless Access Point and on the side of the package. If you ever need to

call our Technical Support department, you will need this number to

receive assistance.

Serial Number

R24.0277.00

Table of Contents

Do you have a question about the USR2249 and is the answer not in the manual?

Page 1 22 Mbps Wireless Access Point Quick Installation Guide Note: For the most updated information, visit: http://www.usr.com/ support. You can also refer to the User Guide on the U.S. Robotics Installation CD-ROM for more detailed information. Prepare for installation Turn on your desktop or laptop computer. Type your password if you are prompted to do so.
Page 2 Install your software Attention: You will need to install this software on all the PCs or laptops you plan to wirelessly network together. Insert your U.S. Robotics Installation CD-ROM into your CD-ROM drive. Note: If the Choose Setup Language window appears, select your preferred language and click OK.
Page 3 The Wireless Access Point has three LED status indicators, LINK, DATA, and POWER. When the Wireless Access Point is plugged in, the PWR LED will illuminate. When a network connection is established, the LINK LED will be green. When there is network activity, the DATA LED will be yellow.
Page 4 OK when you are prompted. When the Web Configuration Utility launches, you can change the information about your wireless network. For more information about both Configuration Utilities for the 22 Mbps Wireless Access Point, refer to the User Guide on the Installation CD-ROM.
