3.3.5
M.2 2230 Key E Connector (CN8)
The CN8 is a M.2 2230 Key E connector. It is suggested to install the M.2 wireless module via
PCIe x1 with 22mm x 30mm (width x length).
Pin
Signal
1
GND
3
USB2_DP5
5
USB2_DN5
7
GND
9
NC
11
NC
13
NC
15
NC
17
NC
19
NC
21
NC
23
NC
25
27
Key E
29
31
33
GND
35
PCIE5_TXP
37
PCIE5_TXN
39
GND
41
PCIE5_RXP
43
PCIE5_RXN
45
GND
47
PCIE_CLKP5
49
PCIE_CLKN5
51
GND
CLKREQ#_PCI
53
E5
55
PCIE_WAKE_N
57
GND
59
NC
61
NC
63
GND
65
NC
67
NC
69
GND
71
NC
73
NC
75
GND
After installing the M.2 Key E card, please follow the red arrow to screw and lock the card. It is
suggested to install M.2 Key E card before DDR4 module on SO-DIMM connector (CN1).
Note
Jumper & Connector Settings
Pin
Signal
2
+3.3V_SBY
4
+3.3V_SBY
6
NC
8
NC
10
NC
12
NC
14
NC
16
NC
18
GND
20
NC
22
NC
24
26
Key E
28
30
32
NC
34
NC
36
NC
38
NC
40
NC
42
NC
44
NC
46
NC
48
NC
50
SUSCLK
(+3.3V Level)
52
PLTRST_2_N
(+3.3V Level)
54
W_DIS2#
(+3.3V Level)
56
W_DI12#
(+3.3V Level)
58
SMBDAT_3P3_SBY
60
SMBCLK_3P3_SBY
62
SMBALERT#_3P3_SBY
64
NC
66
NC
68
NC
70
NC
72
+3.3V_SBY
74
+3.3V_SBY
