eBOX100-51R-FL Series user's Manual
3.3.4 M.2 2242 Key B Connector (CN7)
The CN7 is a M.2 Key B connector. It is suggested to install the M.2 storage module via
SATA (Default) or PCIe x2 for NVMe (BOM Optional) with 22mm x 42mm (width x length).
Pin
Signal
1
CONFIG_3
3
GND
5
GND
7
USB_DP6
9
USB_DN6
11
GND
13
15
KEY B
17
19
21
CONFIG_0
23
GPIO11(+1.8V)
25
NC
27
GND
PCIE12_RXN/
29
SATA2_RXN_C
PCIE12_RXP/
31
SATA2_RXP_C
33
GND
PCIE12_TXN/
35
SATA2_TXN_C
PCIE12_TXP/
37
SATA2_TXP_C
39
GND
SATA3_RXP0 or
41
PCIE11_RXN
SATA3_RXN0 or
43
PCIE11_RXP
45
GND
SATA3_TXN0 or
47
PCIE11_TXN
SATA3_TXP0 or
49
PCIE11_TXP
51
GND
53
PCIE_CLKN3
55
PCIE_CLKP3
57
GND
59
NC
61
NC
63
NC
65
NC
PLTRST_2_1P8_
67
N
69
CONFIG_1
71
GND
73
GND
75
CONFIG_2
24
Pin
Signal
2
+3.3V_SBY
4
+3.3V_SBY
Full Card PWR
6
OFF
8
W_DISABLE#
10
NC
12
14
KEY B
16
18
20
HDA_BCLK
22
HDA_SDO
24
HDA_SDIO
26
NC
28
HDA_SYNC
30
SPI_TPM_MISO
32
SPI_TPM_CLK
34
SPI_TPM_MOSI
36
SPI_TPM_CS_N
38
NC
SMBCLK_1P8_S
40
BY
SMBDAT_1P8_S
42
BY
SMBALERT#_
44
1P8_SBY
46
NC
48
NC
PLTRST_2_N
50
(+3.3V Level)
CLKREQ#_PCIE
52
3
54
PCIE_WAKE_N
56
HDA_RST#
58
NC
60
NC
62
NC
64
NC
66
SPI_TPM_IRQ
SUSCLK
68
(+3.3V Level)
70
+3.3V_SBY
72
+3.3V_SBY
74
+3.3V_SBY
75 74
1
2
After installing the M.2 Key B
card, please follow the red
Note
arrow to screw and lock the
card. It is suggested to install
M.2 Key B card before DDR4
module on SO-DIMM connector
(CN1).
Jumper & Connector Settings
