Introduction; Preparing For Installation - Raven SmarTrax Installation Manual

Case ih puma and new holland t70x0/t7.xxx - steering ready

Hide thumbs Also See for SmarTrax:

Table of Contents

I ntroduction

CHAPTER

C h a p t e r 2

Congratulations on your purchase of the SmarTrax system! This system is designed to provide cutting-edge,

hands-free steering of the machine via Global Positioning System (GPS) coordinates.

This manual applies to the following machines:

MAKE: Case IH

MODEL: Puma (AccuGuide™-Ready)

MAKE: New Holland

MODEL: T70X0/T7.XXX (IntelliSteer™-Ready)

Case IH Puma 195

FIGURE 1.

Before installing the SmarTrax system, park the machine where the ground is level, clean, and dry. Turn off the

machine and leave it turned off for the duration of the installation process. Bleed pressure from the hydraulic

system by loosening the hydraulic fittings slowly, where applicable.

During the installation process, follow good safety practices. Be sure to carefully read the instructions in this

manual as you complete the installation process.

Manual No. 016-5032-007 Rev. B
