Raven SmarTrax Installation Manual page 9
Case ih stx/steiger/quadtrac (accuguide - ready) and new holland tj/t90x0/t9.xxx (intellisteer - ready)
Hide thumbs
Also See for SmarTrax:
- Calibration and operation manual (156 pages) ,
- Operation manual (73 pages) ,
- Installation manual (59 pages)
Table of Contents
Advertisement
SmarTrax Installation Kit (P/N 117-5032-002)
TABLE 1.
Manual No. 016-5032-002 Rev. C
Item Description
Node - SmarTrax RTK
Interface - Case IH Box
Plate - Node Mounting
Cable - Case IH Steiger/Quadtrac SmarTrax
Node
Assembly - SmarTrax Enable Foot Switch
Switch - Master
Bolt - M6 x 1.0 x 2.0
Nut - 3/8"-16 Nylon Insert Lock
Nut - M6 x 1.0 Lock
Washer - 1/4" Zinc Split Lock
Washer - 0.250" ID x 0.562" OD x 0.065
Thick
Introduction
Part Number
Qty.
063-0173-228
1
063-0173-038
1
107-0172-084
1
115-4001-092
1
063-0172-470
1
412-2011-104
1
311-0070-010
4
312-4000-061
3
312-4000-207
4
313-1000-016
4
313-2300-009
4
5
