Install the SmarTrax Node - Model Year 2011
& Newer
Install the SmarTrax Node
Instructional Seat Mounting Screws
FIGURE 4.
Uninstall the instructional seat cushion by removing the screws that secure it to the frame.
1.
Remove any contents from under the instructional seat.
2.
Floor Mat Removed from Cab
FIGURE 5.
Lift the floor mat from the floor in front of the seat.
3.
Manual No. 016-5032-002 Rev. C
Cab Component Installation
9
