CaseIH 4300 SmarTrax Supplement & Installation Manual

Basic Kit

Contents
2
Below you will see the kit contents that you should have received with this
SmarTrax kit.
CaseIH 4300 SmarTrax Kit Contents
Quantity Item Description
1 Sensor, Yaw
1 Cable, Hydraulic Solenoid/Override
1 Weldment, Bracket, Universal Hydraulic Mounting
1 Kit, Hyd., SmarTrax, CIH 4300 Floater, '97 & Earlier
1 Valve, Flow Control, 1/4" NPTF, w/Fittings
1 Valve, Hyd., MM, Dual Counterbalance, w/FTGS
1 Switch, Press., Micro, HD, 15-100 BAR ADJ., w/
Fitting
4 Bolt, 5/10-18 x 7/8" Hex
2 Bolt, Machine, 5/16-18 UNC x 3" LONG
2 Nut, Hex, 5/16-18 UNC
4 Nut, 3/8-16
6 Washer, 5/16 Lock, Split
2 Washer, .312 I.D. x .734 O.D.
4 Washer, Flat, 3/8"
1 Valve, Hyd., Open Center, PWM
1 Manual, Installation
1 Manual, Installation, SmarTrax
1 Label, Warning, Do Not Step
1 Label, Warning, Tampering
1 FTG., Adapter, Swivel Run Tee, -8 JIC M/M/F
1 FTG., Elbow, 45° Swivel, -8 JIC M/F
5 FTG., Elbow, 90° Swivel, -6 JIC M/F
4 FTG., Adapter, Swivel Run Tee, -6 JIC M/M/F
1 FTG., Elbow, 90° Swivel, -8 JIC M/F
2 FTG., Adapter, STR., -6 JIC (F) To -8 JIC (M)
2 Hose, Hyd., -8 JIC (F) to -6 JIC (F), 24"
1 Hose, Hyd., -8 JIC (F) to -8 JIC (F), 18"
1 Hose, Hyd., -8 JIC (F) 90° to -6 JIC (F), 18"
3 Hose, Hyd., -6 JIC (F) 90° to -6 JIC (F), 12"
Part Number
063-0172-684
115-0171-466
116-0159-527
117-0194-072
334-0001-053
334-0003-026
422-0000-073
311-0052-104
311-0052-113
312-1001-034
312-1001-037
313-1000-022
313-2300-011
313-2300-013
334-0003-064
016-0190-072
016-9001-012
041-0159-688
041-0159-689
333-0012-039
333-0012-040
333-0012-042
333-0012-043
333-0012-064
333-0012-118
214-1000-171
214-1000-250
214-1000-428
214-1000-429
