Mounting the
Counterbalance
Valve, Pressure
Switch, and
Needle Valve
1. Connect the pressure switch with the tee fitting to the brake port of the
counterbalance valve.
2. Attach the needle valve to the open port of the tee of the pressure
switch.
Manual # 016-0190-072
C
H A P T E R
H
Y D R A U L I C S
7
